Specifications
| Specification | Value |
|---|---|
| Load Capacity | 1,800 kg |
| Standard Lift Height | 5,500 mm |
| Load Centre | 500 mm |
| Turning Radius | 2,900 mm |
| Travel Speed (laden) | 24 km/h |
| Engine | Yanmar 4TNE98 diesel (42.1 kW, Stage IIIA / EPA Tier 3) |
| Starter Battery | 12V / 90Ah |
| Mast Type | Wide-view duplex |
| Mast Tilt | 10° forward / 12° back |
| Overall Length | 4,245 mm (forks included) |
| Overall Width | 1,557 mm |
| Wheelbase | 1,880 mm |
| Ground Clearance (laden) | 240 mm |
| Service Weight | 4,670 kg |
| Tyre Type | Pneumatic (Front: 12-16.5-14PR / Rear: 27x10-12-12PR) |
| Gradeability (laden) | 27% |
| Drawbar Pull (laden) | 21,000 N |
Applications
- Construction sites and building supply — moves palletised bricks, blocks, structural steel, timber, and bagged materials across uneven site ground where standard forklifts cannot safely operate; suited to sites without hardstand areas and with mixed terrain access routes
- Agriculture and rural operations — handles bulk bags, wrapped bales, palletised feed and chemicals, and rural machinery components on farm tracks, paddock edges, and shed approaches that standard warehouse forklifts cannot access
- Infrastructure and civil works — positions pipe, concrete products, drainage materials, and plant components on active civil sites where ground conditions change daily and machine ground clearance is essential
- Outdoor events, markets, and temporary installations — sets up and strikes staging, fencing, generators, and heavy equipment on grass or gravel venues where wheeled access equipment is unsuitable and a compact footprint is required
